Epcon™ C8 Xtrem™

Independently tested and assessed for 100 year design life under sustained loading, means peace of mind for design engineers and building contractors alike. Versatile Epcon™ C8 Xtrem™ is suitable for extreme anchoring environments including seismic, cracked concrete, core drilled holes, oversized diameters, flooded conditions and underwater. Epcon™ C8 Xtrem™ is ideal for applications requiring the highest bond strength and security. It accommodates a wide range of climate conditions and is easy to dispense in cold weather. Its long working time is ideal for deep embedment or hot climates.

Before visiting a Stockist or Service Centre, contact them to ensure product availability.

PART NUMBER:

ADD TO TOOLBOX iEXPERT

Contact Details

Other information

I would like to receive updates on Specials and Offers

-+PRODUCT INFORMATION

Click on the column headings to reorder the table.

ITEM CODE	Pack Size	Material Type	QTY	ADD TO TOOLBOX
C8-450	450ml	Pure Epoxy	12

STEEL ZINC PLATED

STAINLESS STEEL

GALVANISED STEEL

ADD

The selected variations added in the toolbox. Please view the items in the toolbox.

-+FEATURES & BENEFITS

- Meets the highest anchoring standards
- Fast, All Weather Dispensing
- Seismic Design Approved
- Cracked Concrete and Tension Zone
- 100 Year Working Life
- Fire Rated
- Reduced fatigue
- Improved productivity
- No weather delays
- Suitable for dry, damp, wet and flooded holes
- High bond strength
- Suitable for core drilled and carbide drilled holes
- Long working time
- 11 minutes at 20°C
- Longer nozzle life
- More time to insert bars into deep holes
- No shrink epoxy
- Oversized holes up to 2.25 x bar diameter
- User friendly
- Low odour

-+APPLICATIONS & TRADES

Post-installed reinforcing bar	Construction contractor, Civil contractor, Formworker, Building contractor
Starter bars	Construction contractor, Civil contractor, Formworker, Building contractor

-+TECHNICAL DATA & DOCUMENTS

RAMSET PRODUCT CATALOGUE	PDF
RAMSET SPECIFIERS PRODUCT GUIDE	PDF
EPCON™ C8 FLYER	PDF
EPCON™ C8 CATALOGUE	PDF
EPCON™ C8 SDS	PDF
EPCON™ C8 XTREM INJECTION WITH ANCHOR STUDS	PDF
EPCON™ C8 XTREM SEISMIC ANCHOR STUD	PDF
EPCON™ C8 XTREM INJECTION WITH REINFORCING BAR	PDF
EPCON™ C8 XTREM SEISMIC REINFORCING BAR	PDF
EPCON™ C8 XTREM FIRE RATED ANCHORING SYSTEMS	PDF
EPCON™ C8 XTREM POTABLE WATER CONSUMPTION	PDF
EPCON™ C8 XTREM Seismic C2	PDF
EPCON™ C8 XTREM ETA PART 1	PDF
EPCON™ C8 XTREM ETA PART 2	PDF
EPCON™ C8 XTREM ETA	PDF
EPCON™ C8 XTREM ETA 07-0189	PDF
EPCON™ C8 XTREM FTA	PDF
EPCON™ C8 XTREM TDS	PDF
EPCON™ C8 XTREM VOC DATA SHEET	PDF
REO 502™ PLUS, CHEMSET™ 801 XTREM™ XC², EPCON™ C8 XTREM	PDF

-+SPECIFICATIONS

Mixed Colour	Grey
Working Time @ 20°C	11 minutes
Loading Time @ 20°C (Dry)	16 hours
Loading Time @ 20°C (Flooded)	32 hours
Minimum Substrate Temperature	5°C
Minimum Adhesive Temperature	5°C
Service Temperature Limts	-40°C to +80°C
Resistivity §Ù.cm	5 x 1015
Compressive Strength NF EN ISO 604	115 MPa
